An antiquated version of Cisco VPN used by a new client was being stubborn and failing to install on my machine. I was getting error 27850, stating something in my system was “corrupted”.
I had a hunch that the installer was conflicting with Cisco AnyConnect, a more modern version of Cisco’s VPN implementation, a program I had uninstalled after finishing up at a previous client.
I dumped the MSI installer log file and sifted through to find a more detailed error.
msiexec.exe /i "vpnclient_setup.msi" /L*V "C:\log.log"
And the result was a 1MB text file. The concerning portion was:
MSI (s) (C8:BC) [14:39:31:368]: Invoking remote custom action. DLL: C:\WINDOWS\Installer\MSI19B4.tmp, Entrypoint: InstallDNE
1: DNECA: RunDNEInstall dneinst command line ‘”C:\Program Files\Common Files\Deterministic Networks\Common Files\dneinst.exe” -Install -InstallPath “C:\Program Files\Common Files\Deterministic Networks\DNE”‘
Action 14:39:31: Managing Network Components. Installing Network Components. This may take several minutes.
Managing Network Components: Working (1)
MSI (c) (80:10) [14:39:32:720]: Note: 1: 2262 2: Billboard 3: -2147287038
1: DNECA: -2147467262 (0x80004002)
Internal Error 2835. ErrorIcon, ErrorDialog
not found on dialog ErrorDialog
Error 27850. Unable to manage networking component. Operating system corruption may be preventing installation.
MSI (s) (C8!74) [14:39:33:955]: Product: Cisco Systems VPN Client 5.0.07.0290 — Error 27850. Unable to manage networking component. Operating system corruption may be preventing installation.
1: DNECA: —–>> InstallDNE Exit exception handler returning g_iExitCode=0x643
CustomAction Dne64InstallExecFn.BEE04CD6_610D_4F5B_AC11_6AD2E290CC1D returned actual error code 1603 (note this may not be 100% accurate if translation happened inside sandbox)
It looked like the DNE portion of the VPN was failing to install. After some more searching I found a separate installer for DNE on Citrix’s website. I downloaded and installed the DNE installer. When trying to install it threw an error about a registry key. It was unable to modify HKLM/SYSTEM/CurrentControlSet/Services/DNE. I deleted this registry key and re-ran the installer. It went through successfully! After that I ran the original VPN installer, which also worked!
Of course that wasn’t the end of it. After importing the client’s VPN connection information, I got error “Reason 442: Failed to enable Virtual Adapter”
The mighty Google lead me to an IT That Should Just Work post solving this issue via a simple registry edit. After modifying the name of the adapter the VPN was then able to connect!
Browse to the registry key HKLM\SYSTEM\CurrentControlSet\Services\CVirtA
Select the display name to modify:
x86 – “@oem8.ifn,%CVirtA_Desc%;Cisco Systems VPN Adapter” to “Cisco Systems VPN Adapter”
x64 – “@oem8.ifn,%CVirtA_Desc%;Cisco Systems VPN Adapter for 64-bit Windows” to “Cisco Systems VPN Adapter for 64-bit Windows”
